Medical Electric Wheelchair Battery Description

25.2V 6.6Ah Li-ion Wheelchair Battery for Medical Electric Wheelchair

We can manufacture custom 25.2V 6.6Ah Li-ion Wheelchair Battery for Medical Electric Wheelchair according to our customer's request, and we can use your LOGO to your custom battery!

Electric Wheelchair Battery Description:
1. Nominal Capacity : 6.6Ah (0.2C5A Discharge)
2. Nominal Voltage : 25.2V
3. Discharge Cut-off Voltage : 19.25
4. Charge Current : 1320mA(0.2C5A) 0～40℃
5. Charge Voltage : 29.5±0.1V 4.2*7
6. Constant Max Charge Current : 3000mA(0.5C5A) 0～40℃
7. Constant Max Discharge Current : 10000mA(0.5C5A) -20～60℃
8. Application : Medical electric scooter
9. Battery Pack dimension : Max：150.5×64.5×93.5mm Tolerance:±0.5mm

How to select a correct battery for your devices :

1. You need to know your device :
a. What is your device's input voltage? ( V )
b. What is its power consumption? ( Wattage )
c. What is Maximum current drain? ( A )
d. What is your expected running time by a battery pack?

2. Decide battery pack voltage you must be equal or a little higher than your device’s need.

3. Decide Battery pack's Capacity is depended on how long you need to run your device(hours)
Calculated the Capacity as the follow :
( Ah) = Device's Wattage (W) x Time to run ( Hours) / Battery Voltage (V)
